Choose TheColor You Love

Matte Axis Grey Metallic

Matte Cyber Yellow

Pearl Siren Blue

Pearl Spartan Red

E-Brochure

Features

TechnicalSpecifications

Body Dimensions

Body Dimensions

Length X Width X Height 1829mm X 707mm X 1167mm
Wheel Base 1260mm
Ground Clearance 171mm
Kerb Weight 108kg
Seat Length 708mm
Fuel Tank Capacity 5.3L

Engine

Type Fan Cooled, 4 Stroke, SI Engine
Displacement 124cc
Max Engine Output 6.07 Kw @ 6000 rpm
Max Torque 10.3 N-m @ 5000 rpm
Fuel System PGM-FI
Bore X Stroke 50.0 X 63.1mm
Compression Ratio 10:1
Air Filter Type Viscous Paper Filter
Starting Method Kick/self

Transmission

Clutch Type Automatic (V-matic)

Tyres & Brakes

Tyre Size (Front) 90/90-12 54J
Tyre Size (Rear) 90/100-10 53J
Tyre Type (Front) Tubeless
Tyre Type (Rear) Tubeless
Brake Type & Size (Front) Disc-190 mm
Brake Type & Size (Rear) Drum-130 mm

Frame and Suspension

Frame Type Under Bone
Front Suspension Telescopic
Rear Suspension 3 Step Adjustable, Spring Loaded Hydraulic Type

Electricals

Battery 12V, 5.0 Ah
Head lamp LED, DC

Price

Model Show Room Price
GRAZIA DRUM
GRAZIA DISC

Accessories

Book a Test Ride
